150 Khz Ultrasonic Transducer
Ultrasonic transducer is designed for rugged use on construction sites and similar outdoor environments.This transducer is built to both send and receive ultrasonic waves and convert them to a voltage output.
Product Information
Specifications
Enquiry
| Uses | For fine-grained materials (sand sized) For masonry (refractory) bricks |
| Weight | 85 g / 0.19 lbs. |
| Case Dimensions | Diameter 25 mm x Length 34 mm (0.98 in. x 1.34 in.) |
| Housing | Stainless steel, ruggedised |
| Element | Piezoelectric ceramic |
| Frequency | 150 kHz centre |
| Operating Temperature | -10 to 40°C |
| Excitation | Typically HV 1000 V @ 5 µs; LV 600 V @ 5 µs |
